Features
 • Reliable surge protection for all Lorentz pump accessories.
 • Can be installed inside the PS Controller.

Technical Data
 • Max. Voltage - 14 VDC.
 • Max current 8/20µs - 500 A.
 • Enclosure class: IP54.
 • Ambient temperature - max. 50°C.
 • Wire size - 2x 1.5mm² or AWG 16.

Dimensions / Weight
 • Packing dimensions - 70mm x 45mm x 20 mm.
 • Total weight - 0.1 kg.
